| LCD monitor information |
|
| Model Number |
AXD-10OPN1P2-C |
| 10.4’’Open frame touch monitor |
| Type |
10.4 “ TFT Active Matrix LCD with LED Backlight |
| Active Display Area(mm) |
211.2 (H)x158.4(V) |
| Pixel Pitch(mm) |
0.264(H)x0.264(V) |
| Resolution |
1024X768 |
| Contrast Ratio |
600:1 (typ.) |
| Display Color |
16.2 M colors |
| Brightness |
350(Typ) |
| Viewing Angles |
140(H);120(V) |
| Response Time |
8ms |
| Environmental Temperature |
|
| Operating Temperature |
-20℃~70℃ |
| Storage Temperature |
-30℃~80℃ |
| Signal Input |
|
| PC |
RGB analog VGA; DVI-D |
| RGB Frequency |
H:31.5~38kHz, V:50~60Hz |
| Power Specification |
|
| Voltage Consumption |
AC 100~240V,Universal,±10% ; AC/DC 12V4A |
| 6.3W typical, normal operation |
| Touch Screen Optional |
Pro-Capacitive Touch |
| Touch Type |
10 points multi-touch |
| Dimensions |
| Holes fixings |
rugged metal frame Vesa mounting 75×75 |
| Mechanical dimensions |
230.5 x 181.5x 29.9 (mm) |
| Drawings |
Please contact us for details |
