Wall Mounting 1280×1024 TFT Liquid Crystal Display Monitor 4:3 For Kiosk

Brand :

Model: AXD-17OPN1P1-VHT4

Screen Size:17’’

Screen format: 4:3

Display Resolution(pixel):1280×1024

Contrast Ratio:800:1

Brightness:1000cd/m^2

Storage temperature : -10℃~60℃

Input signal: VGA DVI

Power Input: DC 12V

Category: IP65 Touch Monitor

Display Specifications
Display	17″ Color TFT Open Frame Monitor (1000NITS)
Model Name	AXD-17OPN1P1-VHT4
Active Display Area (mm)	337.92(H)x270.33(V)
Pixel Pitch (mm)	0.264(H)x0.264(V)
Resolution (Pixel)	SXGA (1280X1024) 262K/16.2MColor
Brightness (CD/m^2)	1000cd/m^2
Contrast Ratio	1000:1
Viewing Angle (CR >=10)	170/160
Power consumption	33.8W typical, normal operation
Touch Screen	Resistive; SAW ;RS232/USB(Optional)
OSD Control	On the back side
I/O Connectors	1x12v,1XVGA,DVI-D(Optional)
Power Input	DC 12V,4A48W
Mechanical Specifications
Construction	Steel metal chassis & Galvanized Color
Dimensions	387.60 x 333.4x 45.30 (mm)
Mounting	embedded optional
Power source	AC 100~240V/ 12V DC
Environment Specifications
Operating Temperature	-10~60℃
Storage Temperature	-20~70℃
Rating	Facilitate installation of the demolition,solid portfolio
Ordering Information	17” 1000nits sunlight readable OP Monitor with VGA input and power adapter
