| Panel PC information |
|
| Model Number |
AXD-08PPC-A2 T1 |
| 8.0’’ Android Touch panel pc |
|
| Case/Bezel Color |
Black |
| TFT Type |
industrial LED Based LCD |
| Aspect ratio |
4:3 |
| Useful Screen Area |
162.0(H)x121.5(V) |
| Touch Panel |
Resistive touch |
| Touch response time |
10ms (typical |
| Touch PC Dimensions |
162.0(H)x121.5(V) |
| Optimal (native) Resolution |
800×600 |
| LCD panel Pixel pitch |
0.1695 x 0.1695 mm |
| LCD panel Colors |
262K/16.7 million |
| LCD panel Brightness |
250 cd/m2 |
| LCD panel Response Time |
25 ms |
| Contrast Ratio |
500:1 |
| Viewing Angle ( Wide ) |
|
| Horizontal (left/right) |
±60° or 120° total |
| Vertical (up/down) |
55°(up), 55°(down) or 110° total |
| Output Interface |
USB/Rs232 Options |
| Net |
Internet LAN |
| Watch Dog Technology |
Support |
| Power Specification |
External AC to DC power brick |
Wide voltage from 9V-24V |
|
| AC to DC power brick input: 100-240 VAC, 50/60 Hz |
|
| Power dissipation: 6W max |
|
| ECM (Embed Computer Module) |
Quad Core ARM CORTEX-A 9 DDR3: 1G; NAND :8G; Operation System:Android O.S 4.4 |
| Temperature |
Operating: -10°C to 60°C ;Storage -20°C to 70°C |
| Humidity (non condensing) |
20%RH –95%RH |
| Shipping Carton Dimensions |
490 x 440 x340 mm (Five pieces in one ) |
| Weight (approx.) |
Actual: 11kg ;Shipping: 15kg |
| Dimensions |
|
| Holes fixings |
Vesa mounting 100×100 |
| Drawings |
Please contact us for details
|
