Display Specifications | |
Display | 21.5″ Open frame LED Monitor with IPS |
Model Name | AXD-21OPN1P1-V3 |
Active Display Area (mm) | 476.64 (H)x268.11(V) |
Pixel Pitch (mm) | 0.282(H)x0.282(V) |
Resolution (Pixel) | WSXGA (1920X1080) |
Brightness (CD/m^2) | 250cd/m^2 |
Contrast Ratio | 1000:1 |
Viewing Angle (CR >=10) | 89/89/89/89 super wide viewing angle |
Power consumption | 23.6 W typical, low consumption ,normal operation |
Touch Screen | Resistive RS232/USB(Optional) |
OSD Control | On the back side |
I/O Connectors | 1x12v,1XVGA,DVI-D(Optional) |
Power Input | DC 12V,4A48W |
Mechanical Specifications | |
Construction | Steel metal housing |
Dimensions | 522.0x 294.6x 33.0(mm) |
Mounting | Embedded ,fixing holes on the edging frame |
Power source | AC 100~240V/ 12V DC |
Environment Specifications | |
Operating Temperature | 0~60℃ |
Storage Temperature | 0~60℃ |
Rating | Facilitate installation of the demolition,solid portfolio |
Ordering Information | 21.5” LED Open frame FHD IPS Technology with VGA input and power adapter |
21.5 Inch IPS LED Backlight LCD Monitor 1920×1080 For Outdoor Advertising
Brand :
Model: AXD-21OPN1P1-V3
Screen Size:21.5
Screen format: 16:9
Display Resolution(pixel):1920X1080
Contrast Ratio:1000:1
Brightness:250cd/m^2
Storage temperature : 0℃~60℃
Input signal: VGA DVI
Power Input: DC 12V
Product status: Stock
