27 Inch Full HD Android Panel PC With Anti Vandal Pro Capacitive Touch

Brand :

Screen Size: 27
Screen format:  16:9
Display Resolution(pixel): 1920X1080
Contrast Ratio: 3000:1
Brightness: 300cd/m^2
Storage temperature :  -20℃~60℃
Operating temperature :  0 to 60°C
Power Input:  DC 12V
Touch Type:  Capacitive Touch
Product status:  Stock



Display Specifications

Display
27″ Color TFT Android touch monitor
Model Name
AXD-27OPN1P2-T2 A
Active Display Area (mm)
597.6 (H)x336.15(V)
Pixel Pitch (mm)
0.363(H)x0.363(V)
Resolution (Pixel)
WSXGA (1920X1080)
Brightness (CD/m^2)
300cd/m^2
Contrast Ratio
3000:1
Viewing Angle (CR >=10)
178/178
Power consumption
30W typical, normal operation
Touch Screen
Capacitive RS232/USB(Optional)

Construction

G+G Anti-vandal Glass
OSD Control
On the back side
I/O Connectors
1x12v,1XVGA,DVI-D(Optional)
Power Input
Touch Screen options
220v
Projected Capacitive Touch panel
CPU(Embed Computer Module)
Quad Core ARM CORTEX-A 9
DDR3: 2G; NAND :8G
Operation System:Android 4.42
Mechanical Specifications

Construction
Steel metal housing
Dimensions
650.0x 380.0x 55.2(mm)
Mounting
Embedded ,fixing holes on the
Power source
AC 100~240V/ 12V DC
Environment Specifications

Operating Temperature
0~60℃
Storage Temperature
-20~60℃
Rating
Facilitate installation of the demolition,solid portfolio
Ordering Information
27” Open frame IR touch LCD HD with 300nits brightness monitors

 Features and Advantages


1. High Resolution with high contract AUO LCD in stable supply
2. 178/178 wide viewing angle with high performance
3. Integrated solution for touch screen and LCD display; good performance and easy assembling.
4. Interface both for USB and RS232 is available. Andriod O.S 4.42 would be provided.
5. Higher sensitivity and faster response
6. Long durability;300nits high brightness LCD panels for this industrial monitor grade
7. Multi-options for assembling, including vertical, horizontal support. You may assemble it in VESA standard solution or in your own design.
8.We also provide the service of producing the product in users’ own design.
