| LCD monitor information |
|
| Model Number |
AXD-08OPN1P3-V2 |
| 8” digital LED monitor |
| Type |
8 ” TFT Active Matrix LCD with LED Backlight |
| Active Display Area(mm) |
162.0(H)x121.5(V) |
| Pixel Pitch(mm) |
0.213(H)x0.213(V) |
| Resolution |
800 x 600, up to 1024X768 |
| Contrast Ratio |
500:1 (typ.) |
| Display Color |
16.7 M colors |
| Brightness |
250(Typ) |
| Viewing Angles |
140(H);120(V) |
| Response Time |
10ms/15ms |
| Environmental Temperature |
|
| Operating Temperature |
-10ºC~70ºC |
| Storage Temperature |
-20ºC~80ºC |
| Signal Input |
|
| PC |
RGB analog VGA/ h-dmi/ AV |
| RGB Frequency |
H:31.5~38kHz, V:50~60Hz |
| Power Specification |
|
| Voltage Consumption |
AC 100~240V,Universal,±10% ; AC/DC 12V4A |
| 3.3W typical, normal operation |
| Touch Screen Optional |
No touch screen |
| Dimensions |
| Construction |
Rugged chassis & Black Color |
| Holes fixings |
Right Left fixing holes |
| Mechanical dimensions |
223.0 x 158.0x 31.0 (mm) |
| Drawings |
Please contact us for details |
| Features and Advantages |
| 1. New and A grade perfect panels with stable supply |
| 2. Industrial control board supports the displays working 24 hours |
| 3. Professional and industrial hardware and parts to guarantee its working normally in rough environment |
| 4. Open frame with front panel frame design on the surface, rugged mounted frame to protect the LCD screen |
| 5. H-dmi/VGA/AV interfaces |
| 6. 8 inch h-dmi led monitor for Automatic , kiosks, application control ,advertising player , campus and industrial terminals etc |
