| Description | Screen Size:15’’
Screen format: 4:3
Display Resolution(pixel):1280x1024
Contrast Ratio:600:1
Brightness:800cd/m^2
Storage temperature : -10℃~70℃
Input signal: VGA DVI
Power Input: DC 12V
Touch Type: Resistive touch | Screen Size:12''
Screen format: 4:3
Display Resolution(pixel):800X600
Contrast Ratio:700:1
Brightness:400cd/m^2
Storage temperature : -30℃~85℃
Input signal: VGA DVI
Power Input: DC 12V
Product status: Stock | Screen Size:17’’
Screen format: 4:3
Display Resolution(pixel):1280X1024
Contrast Ratio:800:1
Brightness:300cd/m^2
Storage temperature : -10℃~70℃
Input signal: VGA DVI
Power Input: DC 12V
Touch Type: IR Touch
Product status: Stock | Model NO: AXD-10PPC-V2A
Screen Size: 10 Inch
Display Resolution(pixel): 1280x800
Contrast Ratio:800:1
Brightness (CD/m^2): 350cd/m^2
Touch type: Resistive/Capacitive Touch screen
Application: Kiosks,Industrial machines,Automation,etc | Model NO: AXD-08PPC-V2
Screen Size: 8.4 Inch
Display Resolution(pixel): 800x600
Contrast Ratio:600:1
Brightness (CD/m^2): 450cd/m^2
Touch type: Resistive/Capacitive Touch screen
Application: Kiosks,Industrial machines,Automation,etc | Screen Size: 19.0 inch
Display Resolution(pixel):1280x1024
Contrast Ratio:1000:1
Brightness (CD/m^2):400
Touch type: Resistive,IR touch options
Design: IP65 with aluminum front bezel
Application: Kiosks, Digital Signage, Vending ,etc
Minimum Order Quantity:3 Pieces
Price:Depends on product and order quantity
Packaging Details: 3 Pcs /Carton with firm foam |
| Content |
| Display Specifications
|
|
| Display
|
15" Color TFT Panel mount touch Monitor
|
| Model Name
|
AXD-15OPIPPM07-T1
|
| Active Display Area (mm)
|
304.1(H)x304.1(V)
|
| Pixel Pitch (mm)
|
0.297(H)x0.297(V)
|
| Resolution (Pixel)
|
XGA (1024X768) 262K/16.2M Color
|
| Brightness (CD/m^2)
|
800nits
|
| Contrast Ratio
|
600:1
|
| Viewing Angle (CR >=10)
|
160/140
|
| Power consumption
|
23.3W typical, normal operation
|
| Touch Screen
|
Resistive;RS232/USB(Optional)
|
| OSD Control
|
On the back side
|
| I/O Connectors
|
1x12v,1XVGA,DVI-D
|
| Power Input
|
DC 12V,4A 48W
|
| Mechanical Specifications
|
|
| Construction
|
Steel Metal chassis & Black Color
|
| Dimensions
|
398.0 x 295.0x 48 (mm)
|
| Mounting
|
Edge fixing holes, vesa mounting on the backside
|
| Power source
|
AC 100~240V/ 12V DC
|
| Environment Specifications
|
|
| Operating Temperature
|
-10~70℃
|
| Storage Temperature
|
-20~80℃
|
| Rating
|
Facilitate installation of the demolition,solid portfolio
|
| Ordering Information
|
15” Panel mount touch LCD Monitor with VGA input and power adapter
|
|
|
Display Specifications
|
|
Display
|
12.1" Color TFT Industrial Monitor
|
|
Model Name
|
AXD-12OPIPPC-T1
|
|
Active Display Area (mm)
|
246 (H)x184.5(V)
|
|
Pixel Pitch (mm)
|
0.3075(H)x0.3075(V)
|
|
Resolution (Pixel)
|
SVGA (800X600) 262K/16.2M Color
|
|
Brightness (CD/m^2)
|
400cd/m^2 (1000cd/m^2 Optional)
|
|
Contrast Ratio
|
600:1
|
|
Viewing Angle (CR >=10)
|
160/140
|
|
Power consumption
|
15W typical, normal operation
|
|
Touch Screen
|
Resistive ;capacitive Touch ;RS232/USB(Optional)
|
|
OSD Control
|
On the back side
|
|
I/O Connectors
|
1x12v,1XVGA,DVI-D(Optional)
|
|
Power Input
|
DC 12V,4A 48W
|
|
Mechanical Specifications
|
|
|
Construction
|
IP 64 sealing front bezel &Black Color
|
|
Dimensions
|
351.0 x 265.0x 56.0(mm)
|
|
Mounting
|
Embedded ,Wall Mounting Optional
|
|
Power source
|
AC 100~240V/ 12V DC
|
|
Environment Specifications
|
|
|
Operating Temperature
|
-20~75℃
|
|
Storage Temperature
|
-30~80℃
|
|
Rating
|
Facilitate installation of the demolition,solid portfolio
|
|
Ordering Information
|
12.1” industrial Monitor with VGA input and power adapter
|
|
| Display
|
17" Color Industrial Monitor with IR touch (Anti-vandal)
|
| Model Name
|
AXD-17OPIPN1P1-IR
|
| Active Display Area (mm)
|
337.92(H)x270.33(V)
|
| Pixel Pitch (mm)
|
0.264(H)x0.264(V)
|
| Resolution (Pixel)
|
VGA (1280X1024) 262K/16.2MColor
|
| Brightness (CD/m^2)
|
300cd/m^2 |
| Contrast Ratio
|
1000:1
|
| Viewing Angle (CR >=10)
|
170/160
|
| Power consumption
|
25.8W typical, normal operation
|
| Touch Screen
|
IR Touch ;RS232/USB(Optional)
|
| OSD Control
|
On the back side
|
| I/O Connectors
|
1x12v,1XVGA,DVI-D(Optional)
|
| Power Input
|
DC 12V,4A48W
|
| Mechanical Specifications
|
|
| Construction
|
Aluminum front bezel &Black Color
|
| Dimensions
|
440.50 x 354.60x 56.80 (mm)
|
| Mounting
|
Embedded ,VESA Mounting Optional
|
| Power source
|
AC 100~240V/ 12V DC
|
| Environment Specifications
|
|
| Operating Temperature
|
-10~60℃
|
| Storage Temperature
|
-20~70℃
|
| Rating
|
Facilitate installation of the demolition,solid portfolio
|
| Ordering Information
|
17” IP Monitor with VGA input and power adapter
|
 |
| Panel PC information |
|
| Model Number |
AXD-10PPC-V2A |
| 10'' Touch pc |
| Case/Bezel Color |
Sliver |
| TFT Type |
IPS LCD with LED backlight |
| Aspect ratio |
16:10 |
| Useful Screen Area |
220.6 mm x 139.6 mm |
| Touch Panel |
Industrial Resistive Flat Screen |
| Touch response time |
10ms (typical |
| Touch PC Dimensions |
262x 206x53.3 mm |
| Optimal (native) Resolution |
1280 x 800 |
| LCD panel Pixel pitch |
0.1695 x 0.1695 mm |
| LCD panel Colors |
262K/16.7 million |
| LCD panel Brightness |
350 cd/m2 |
| LCD panel Response Time |
25 ms |
| Contrast Ratio |
800:1 |
| Viewing Angle ( Wide ) |
|
| Horizontal (left/right) |
±85° or 170° total |
| Vertical (up/down) |
85°(up), 85°(down) or 170° total |
| Output Interface |
COM/HDMI type/ Audio/Mic |
| Input Interface |
USB*3 |
| Net |
Internet LAN |
| Watch Dog Technology |
Support |
| Power Specification |
External AC to DC power brick |
| Monitor input: +12VDC ±5%,3.0 A; DC Jack (2.5) |
| AC to DC power brick input: 100-240 VAC, 50/60 Hz |
| Power dissipation: 36W max |
| ECM (Embed Computer Module) |
Intel® processor N2930 (1.8GHz + NM10 Chipset);Jetway industrial board
SSD: 32G;Rom:4G(DDR3,max6G);
Operation System:Win7;10; inux
|
| Temperature |
Operating: -10°C to 70°C ;Storage -20°C to 80°C |
| Humidity (non condensing) |
Operating: 20%-90%; Storage: 10%-95% |
| Shipping Carton Dimensions |
490 x 440 x340 mm (Five pieces in one ) |
| Weight (approx.) |
Actual: 11kg ;Shipping: 15kg |
| Dimensions |
| Holes fixings |
Vesa mounting 100x100 |
| Mechanical dimensions |
292x 206x53.3 mm |
| Drawings |
Please contact us for details |
Packaging & Delivery
| Packing details |
1x 10 inch Industrial Touch Panel PC ;
Packed in 5 pieces/carton with protection foam
Optional accessories:1x Power supply cable, 1x power adapter
|
| Delivery terms |
7- working days for stock products after receiving payments;
15 working days for order production
|
Features and Advantages
1. New and A grade lcd panel with other components on stable supply
2. Resistive touchscreen makes the touch sense perfectly
3. High specs of motherboard with high operating speed, you can extend Various ports of external equipment
4. Professional and industrial hardware and parts to guarantee its working normally in rough environment
5. Mounting holes on base bottom for tabletop security;Removable base and VESA mounting option
6. 10'' monitor Touch pc hardware for POS, Gaming, Hotel ,Restaurant terminals, KIOSK etc.
|
| Panel PC information |
|
| Model Number |
AXD-08PPC-V2 |
| 8.4'' MiniTouch pc |
| Case/Bezel Color |
Black |
| TFT Type |
8.4 inch AUO new industrial LCD with LED backlight |
| Aspect ratio |
4:3 |
| Useful Screen Area |
170.4 mm x 127.8 mm |
| Touch Panel |
Industrial Resistive Flat Screen |
| Touch response time |
10ms (typical |
| Touch PC Dimensions |
232x 186x53.3 mm |
| Optimal (native) Resolution |
800X600 |
| LCD panel Pixel pitch |
0.264 x 0.264mm |
| LCD panel Colors |
262K/16.7 million |
| LCD panel Brightness |
450 cd/m2 |
| LCD panel Response Time |
8 ms |
| Contrast Ratio |
600:1 |
| Viewing Angle ( Wide ) |
|
| Horizontal (left/right) |
±80° or 160° total |
| Vertical (up/down) |
65°(up), 65°(down) or 30° total |
| Output Interface |
COM/HDMI type/ Audio/Mic |
| Input Interface |
USB*3 |
| Net |
Internet LANX2 |
| Watch Dog Technology |
Support |
| Power Specification |
External AC to DC power brick |
| Monitor input: +12VDC ±5%,3.0 A; DC Jack (2.5) |
| AC to DC power brick input: 100-240 VAC, 50/60 Hz |
| Power dissipation: 10W max |
| ECM (Embed Computer Module) |
Intel® processor N2600
SSD: 32G;Rom:2G(DDR3,max6G);
Operation System:winxp/Win7/win8/win10/linux |
| Temperature |
Operating: -10°C to 60°C ;Storage -20°C to 70°C |
| Humidity (non condensing) |
Operating: 20%-90%; Storage: 10%-95% |
| Shipping Carton Dimensions |
490 x 440 x340 mm (Five pieces in one ) |
| Weight (approx.) |
Actual: 11kg ;Shipping: 15kg |
| Dimensions |
| Holes fixings |
Vesa mounting 100x100 |
| Drawings |
Please contact us for details |
|
| Display Specifications |
|
| Display |
19" Color TFT Industrial Monitor |
| Model Name |
AXD-19IPN1P1 |
| Active Display Area (mm) |
376.3 (H)x301.1(V) |
| Pixel Pitch (mm) |
0.294(H)x0.294(V) |
| Resolution (Pixel) |
SXGA (1280X1024) 262,144(6 bit + FRC) |
| Brightness (CD/m^2) |
250cd/m^2 ; 300cd/m^2 (Optional) |
| Contrast Ratio |
800:1 |
| Viewing Angle (CR >=10) |
150/150 |
| Power consumption |
28W typical, normal operation |
| Touch Screen |
Resistive, capacitive touch ;IR touch ;RS232/USB(Optional) |
| OSD Control |
On the back side |
| I/O Connectors |
1x12v,1XVGA,DVI-D(Optional) |
| Power Input |
DC 12V,@4A 48W |
| Mechanical Specifications |
|
| Construction |
Aluminum front bezel &Black Color |
| Dimensions |
480.6 x 382.6x 54.8 (mm) |
| Mounting |
Embedded ,Wall Mounting Optional |
| Power source |
AC 100~240V/ 12V DC |
| Environment Specifications |
|
| Operating Temperature |
-10~80℃ |
| Storage Temperature |
-20~80℃ |
| Rating |
Facilitate installation of the demolition,solid portfolio |
| Ordering Information |
19” IP Monitor with VGA input and power adapter |
 |
