1037u Processor 300CD/M2 17 Inch 10ms Multi Touch Panel PC

Brand :

Model NO: AXD-17PPC-V3C

Screen Size: 17 Inch

Display Resolution(pixel): 1280X1024

Contrast Ratio: 800:1

Brightness (CD/m^2): 300cd/m^2

Touch type: Resistive/Capacitive Touch screen

Application: Kiosks,Industrial machines,Automation,etc

Panel PC information
Model Number AXD-17PPC-V3C
17′ Multi panel pc
Case/Bezel Color Black
TFT Type Industrial LCD with LED backlight
Aspect ratio 4:3
Touch Panel Industrial capacitive touch panel
Touch response time 10ms (typical)
Optimal (native) Resolution 1280×1024
LCD panel Pixel pitch 0.296 x 0.296 mm
LCD panel Colors 16.7 million
LCD panel Brightness 300cd/m2
LCD panel Response Time 8ms
Contrast Ratio 800:1
Viewing Angle ( Wide )
Horizontal (left/right) ±80° or 160° total
Vertical (up/down) 85°(up), 85°(down) or 170° total
CPU Intel® Celeron 1037U Dual Core 1.86GHz
storage 16 G SSD ( optional)
Serial Ports 2 x COM ports
USB Ports 4 x USB
LAN 1 x LAN RJ-45 connector
DC Power In 1 x 4-pin connector
Video Port 2X Audio
Other Ports 2x LAN, 1XVGA,1xHDMI,1XLPT
Internal Sockets & Connectors 1 x Compact Flash socket (reserved for OEM project)
Power Specification DC 12V
Working Environment
Temperature Operating: -10°C to 60°C ;Storage -20°C to 65°C
Operating Humidity 5 ~ 90% RH @40°C (non-condensing
Vibration 5 ~ 500Hz, 3Grms Random (with CF/SSD)
Dimensions
Mounting Type Embedded Installation
Mechanical dimensions 386.5 x 318.47 x 57.7 mm
Weight (Net) 7.5 kgs/ piece
Drawings Please contact us for details
