Panel PC information | |
Model Number | AXD-08PPC-A2 C |
8.4” Andriod Touch panel pc | |
Case/Bezel Color | Black |
TFT Type | Industrial LCD with LED backlight |
Aspect ratio | 4:3 |
Touch Panel | Industrial Resistive Flat Screen |
Touch response time | 10ms (typical |
Optimal (native) Resolution | 800×600 |
LCD panel Pixel pitch | 0.1695 x 0.1695 mm |
LCD panel Colors | 16.2 million |
LCD panel Brightness | 450 cd/m2 |
LCD panel Response Time | 14 ms |
Contrast Ratio | 500:1 |
Viewing Angle ( Wide ) | |
Horizontal (left/right) | ±80° or 160° total |
Vertical (up/down) | 60°(up), 60°(down) or 120° total |
Output Interface | VGA/HDMI type/ AV/Rs232 Options |
Input Interface | USB*3 |
Net | Internet LAN |
Watch Dog Technology | Support |
Power Specification | External AC to DC power brick |
Monitor input: +12VDC ±5%,3.0 A; DC Jack (2.5) | |
AC to DC power brick input: 100-240 VAC, 50/60 Hz | |
Power dissipation: 36W max | |
ECM (Embed Computer Module) | Quad Core ARM CORTEX-A 9 DDR3: 2G; NAND :8G Operation System:Android 4.42 |
Temperature | Operating: -10°C to 60°C ;Storage -20°C to 60°C |
Humidity (non condensing) | Operating: 20%-90%; Storage: 10%-95% |
Shipping Carton Dimensions | 490 x 440 x340 mm (Five pieces in one ) |
Weight (approx.) | Actual: 11kg ;Shipping: 15kg |
Dimensions | |
Holes fixings | Vesa mounting 100×100 |
Mechanical dimensions | 262x 206×53.3 mm |
Drawings | Please contact us for details |
Industry Android Touch Panel PC Sun View 8.4 Inch 800X600 RS232 USB RS485
Brand :
Model NO: AXD-08PPC-A2 C
Screen Size: 8.4 Inch
Display Resolution(pixel): 800×600
Contrast Ratio:500:1
Brightness (CD/m^2): 450cd/m^2
Touch type: Resistive/Capacitive Touch screen
Application: Kiosks,Industrial machines,Automation,etc
