Fanless 1280X800 Capacitive Touch Panel PC 350nits Chassis Mount 25ms IPS Computer

Brand :

Model NO: AXD-10OPPC-V2A8

Screen Size: 10 Inch

Display Resolution(pixel): 1280 x 800

Contrast Ratio:800:1

Brightness (CD/m^2): 350cd/m^2

Touch type: Resistive/Capacitive Touch screen

Application: Kiosks,Industrial machines,Automation,etc

Panel PC information
Model Number AXD-10OPPC-V2A8
10” Fanless mini capacitive touch panel pc
Case/Bezel Color Black
TFT Type IPS LCD with LED backlight
Aspect ratio 16:10
Useful Screen Area 220.6 mm x 139.6 mm
Touch Panel Industrial capacitive Flat Screen
Touch response time 10ms (typical
Touch PC Dimensions 281x 200×46 mm
Optimal (native) Resolution 1280 x 800
LCD panel Pixel pitch 0.1695 x 0.1695 mm
LCD panel Colors 262K/16.7 million
LCD panel Brightness 350 cd/m2
LCD panel Response Time 25ms
Contrast Ratio 800:1
Viewing Angle ( Wide )
Horizontal (left/right) ±85° or 170° total
Vertical (up/down) 85°(up), 85°(down) or 170° total
Output Interface COM/HDMI type/ Audio/Mic
Input Interface USB*3
Net Internet LANx2
Watch Dog Technology Support
Power Specification External AC to DC power brick
input: +12VDC ±5%,4.0 A; DC Jack (2.5); DC 24V 3Pin phoenix input
AC to DC power brick input: 100-240 VAC, 50/60 Hz
Power dissipation: 36W max
ECM (Embed Computer Module) Intel® processor J1900 (1.9GHz + NM10 Chipset);SSD: 64G;Rom:4G(DDR3,max6G);Operation System:Win7/10/Vista/Linux
Temperature Operating: -10°C to 60°C ;Storage -20°C to 70°C
Humidity (non condensing) Operating: 20%-90%; Storage: 10%-95%
Shipping Carton Dimensions 490 x 440 x340 mm (Five pieces in one )
Weight (approx.) Actual: 11kg ;Shipping: 15kg
Dimensions
Holes fixings Clamp mount on sides
Mechanical dimensions 281x 200x46mm
Drawings Please contact us for details



Brightness: 350cd/m^2 Contrast Ratio: 800:1
Pixel: 1280X800 Screen Size: 10.1 Inch
Application: Industrial|Kiosk|Medical Device Feature: HD|slim|thin|high Definition
Panel Type: TFT Product Name: Fanless Resistive Touch Panel PC
Technology: IPS;IP55 Treatment On Bezel Voltage: 12V Or 24 V Optional
Ports: 4USB, 1XCOM, 1XVGA, AV ETC
