| Panel PC information |
|
| Model Number |
AXD-24PPC-V3 |
| 24.0” Touch panel pc |
| Case/Bezel Color |
Black/ Silver |
| TFT Type |
Industrial LCD with LED backlight |
| Aspect ratio |
16:9 |
| Touch Panel |
Industrial Multi-touch IR Flat Screen |
| Touch response time |
8ms (typical) |
| Optimal (native) Resolution |
1920X1080 |
| LCD panel Pixel pitch |
0.2482 x 0.2482mm |
| LCD panel Colors |
16.7 million |
| LCD panel Brightness |
350 cd/m2 |
| LCD panel Response Time |
8ms |
| Contrast Ratio |
1000:1 |
| Viewing Angle ( Wide ) |
|
| Horizontal (left/right) |
±85° or 170° total |
| Vertical (up/down) |
85°(up), 85°(down) or 170° total |
| CPU |
Intel® Celeron dual core G2030 3.0GHZ |
| storage |
HDD 500G |
| Serial Ports |
1 x COM port internal |
| USB Ports |
8 x USB 3.0 ports, can expand |
| LAN |
1 x LAN RJ-45 connector |
| DC Power In |
1 x 4-pin connector |
| Video Port |
1X Line-out ( S/ PDIF), 1XMic- in |
| Other Ports |
1x LAN, 1X DVI-D,1xHDMI,1X e SATA (2.0) |
| Internal Sockets & Connectors |
1 x PCI-E sockets (reserved for OEM project) |
| Power Specification |
DC 19V |
| Working Environment |
| Temperature |
Operating: 0°C to 60°C ;Storage -30°C to 70°C |
| Operating Humidity |
5 ~ 90% RH @40°C (non-condensing |
| Vibration |
5 ~ 500Hz, 3Grms Random (with CF/SSD) |
| Dimensions |
| Mounting Type |
Embedded Installation |
| Mechanical dimensions |
Drawings |
| Weight (Net) |
14 kgs/ piece, 2 pieces/ carton |
| Drawings |
Please contact us for details |
