Display Specifications | |
Display | 31.5″ Color TFT High Brightness monitor |
Model Name | AXD-32OPN1P3-TH4 |
Active Display Area (mm) | 698.4 (H) x 392.95 (V) |
Pixel Pitch (mm) | 0.363 (H) x 0.363(V) |
Resolution (Pixel) | 1920X1080 |
Brightness (CD/m^2) | 1000cd/m^2 |
Contrast Ratio | 1500:1 |
Viewing Angle (CR >=10) | 178/178 |
Power consumption | 55 W typical, normal operation |
Touch Screen | NO ;capacitive ;IR Touch ;RS232/USB(Optional) |
OSD Control | On the back side |
I/O Connectors | 1x3pin Power plug,1XVGA,DVI-D;HDMI;S-video etc |
Power Input | AC 100~240V,Universal,±10% ; AC/DC 12V4A |
Mechanical Specifications | |
Construction | Roasted Metal Frame |
Dimensions | 791x 453x 76(mm) |
Mounting | Left-right fixing holes ,VESA 75×75(100×100) |
Power source | AC 100~240V |
Environment Specifications | |
Operating Temperature | -10~60ºC |
Storage Temperature | -20~70ºC |
Rating | Facilitate installation of the demolition, solid portfolio |
Ordering Information | 32″ Sunlight readable Monitor 1000nits with full HD |
1000nits High Brightness Monitor 32 Inch Full HD VGA DVI 50walt with AC110 ~ 240V
Brand :
ScreenSize:32”
Display Resolution(pixel):1920X1080
Contrast Ratio:1500:1
Brightness(CD/m^2):1200 cd/m2
Touch type: NO ;capacitive ;IR Touch ;RS232/USB
