| Description | Model NO: AXD-10PPC-V3A
Screen Size: 10.4 Inch
Display Resolution(pixel): 800X600
Contrast Ratio:600:1
Brightness (CD/m^2): 350cd/m^2
Touch type: Resistive/Capacitive Touch screen
Application: Kiosks,Industrial machines,Automation,etc | Quick Details:
Model: AXD-12PPC-A1
Screen Size:12.1
Screen format: 4:3 Display
Resolution(pixel):800x600
Contrast Ratio:500:1
Brightness:400cd/m^2
Storage temperature : -20℃~80℃
Touch Type: Resistive Touch screen
Power Input: DC 12V
MOQ: 1 Piece | Screen Size: 13.3 inch
Display Resolution(pixel):1280x800
Contrast Ratio:600:1
Brightness (CD/m^2):300
Touch type: Resistive;capacitive
Application: Kiosks, Industrial machines, Automation ,etc
Minimum Order Quantity: 10 Pieces
Price:Depends on product and order quantity
Packaging Details: 3 Pcs /Carton with firm foam
Delivery Time: 15 working days for production order | Model NO: AXD-17PPC-A1
Screen Size: 17 Inch
Display Resolution(pixel): 1280X1024
Contrast Ratio:800:1
Brightness (CD/m^2): 300cd/m^2
Touch type: Resistive Touch screen
Application: Kiosks,Industrial machines,Automation,etc | 1280X1024 Industrial Touch Panel PC 19 Inch Touch Screen LCD Monitor
Model NO: AXD-19OPPC-V1
Screen Size: 19 Inch
Display Resolution(pixel): 1280X1024
Contrast Ratio:1000:1
Brightness (CD/m^2): 350cd/m^2
Touch type: Resistive/Capacitive Touch screen
Application: Kiosks,Industrial machines,Automation,etc | Model: AXD-26OPN1T1-VT4
Screen Size:26’’
Screen format: 16:9
Display Resolution(pixel):1920X1080
Contrast Ratio:1500:1 Brightness:400cd/m^2
Storage temperature : -10℃~60℃
Input signal: VGA DVI
Power Input: DC 12V
Touch Type: IR touch
Product status: Stock |
| Content |
| Panel PC information |
|
| Model Number |
AXD-10PPC-V3A |
| 10.4'' Industrial touch panel pc |
| Case/Bezel Color |
Black |
| TFT Type |
Industrial LCD with LED backlight |
| Aspect ratio |
4:3 |
| Touch Panel |
capacitive touch panel |
| Touch response time |
8ms (typical) |
| Optimal (native) Resolution |
800X600 |
| LCD panel Pixel pitch |
0.264 x 0.264 mm |
| LCD panel Colors |
16.2 million |
| LCD panel Brightness |
350 cd/m2 |
| LCD panel Response Time |
8ms |
| Contrast Ratio |
600:1 |
| Viewing Angle ( Wide ) |
|
| Horizontal (left/right) |
±70° or 140° total |
| Vertical (up/down) |
60°(up), 70°(down) or 130° total |
| CPU |
Soldered onboard Intel® Celeron J1900 2.0GHz
Processor; DDR3 800MHz SDRAM |
| storage |
64G SSD |
| Serial Ports |
2x COM ports could be installed if needed. |
| USB Ports |
4x USB external ports ; 6 six USB internal ports |
| LAN |
1x LAN RJ-45 connector; could be two for options |
| Net |
1 x Realtek RTL8111C Gigabit Ethernet controller |
| DC Power In |
1 x DC Jack 2.5 |
| Video Port |
1 x HDMI |
| Watch Dog Timer |
1~255 levels reset |
| Internal Sockets & Connectors |
1 x Compact Flash socket (reserved for OEM project) |
| Power Specification |
DC 12V;DC8-40V for options |
| Working Environment |
| Temperature |
Operating: -10°C to 60°C ;Storage -20°C to 70°C |
| Operating Humidity |
5 ~ 90% RH @40°C (non-condensing |
| Vibration |
5 ~ 500Hz, 3Grms Random (with CF/SSD) |
| Shock |
Operating 16G, 11ms & Non-operating 4G, 20ms (with |
| Dimensions |
| Mounting Type |
Embedded Installation |
| Weight (Net) |
5.0 kgs/ piece |
| Drawings |
Please contact us for details |
Features and Advantages
1,Fanless passive cooled mainboard with low consumption
2, 4G RAM, 64G SSD for memory
3. capacitive touchscreen makes the touch sense perfectly
4. Mounting holes on base bottom for tabletop security; VESA mounting on the backside
5. 10.4''industrial Touch pc hardware for industrial terminals, Automatic applications, KIOSKs etc.
 |
| Panel PC information |
|
| Model Number |
AXD-12PPC-A1 |
| 12.1’’ Touch panel pc |
| Case/Bezel Color |
Black |
| TFT Type |
Industrial LCD with LED backlight |
| Aspect ratio |
4:3 |
| Touch Panel |
Industrial 5 wire Resistive Flat Screen |
| Touch response time |
10ms (typical) |
| Optimal (native) Resolution |
800 x 600/1024x768 |
| LCD panel Pixel pitch |
0.264 x 0.264 mm |
| LCD panel Colors |
16.2 million |
| LCD panel Brightness |
550 cd/m2 |
| LCD panel Response Time |
8ms |
| Contrast Ratio |
500:1 |
| Viewing Angle ( Wide ) |
|
| Horizontal (left/right) |
±70° or 140° total |
| Vertical (up/down) |
70°(up), 70°(down) or 140° total |
| CPU |
Soldered onboard Intel® Atom™ 1037U 1.8GHz
Processor; |
| storage |
128G SSD ; 4G RAM |
| Serial Ports |
2 x COM ports (1x RS-232/422/485 by-pin connector) |
| USB Ports |
2 x USB external ports ; 6 six USB internal ports |
| LAN |
1 x LAN RJ-45 connector |
| Net |
1 x Realtek RTL8111C Gigabit Ethernet controller |
| DC Power In |
1 x 3-pin connector |
| Watch Dog Timer |
1~255 levels reset |
| Internal Sockets & Connectors |
1 x Compact Flash socket (reserved for OEM project) |
| Power Specification |
DC 12V;DC 24V |
| Working Environment |
| Temperature |
Operating: -10°C to 60°C ;Storage -30°C to 75°C |
| Operating Humidity |
5 ~ 90% RH @40°C (non-condensing |
| Vibration |
5 ~ 500Hz, 3Grms Random (with CF/SSD) |
| Shock |
Operating 16G, 11ms & Non-operating 4G, 20ms (with |
| Dimensions |
| Mounting Type |
Panel Mount Installation with clamps |
| Mechanical dimensions |
344 x 263 x 58 mm |
| Weight (Net) |
5.5 kgs/ piece |
| Drawings |
Please contact us for details |
 |
| Model Number |
AXD-13OPPC-VI3 |
| 13’’ Open Frame built panel pc |
| Case/Bezel Color |
white |
| TFT Type |
Industrial LCD with LED backlight |
| Aspect ratio |
4:3 |
| Touch Panel |
Industrial PCAP /Resistive Flat Screen |
| Touch response time |
8ms (typical) |
| Optimal (native) Resolution |
1280X800 |
| LCD panel Pixel pitch |
0.297 x 0.297 mm |
| LCD panel Colors |
16.7 million |
| LCD panel Brightness |
400 cd/m2 |
| LCD panel Response Time |
5ms |
| Contrast Ratio |
500:1 |
| Viewing Angle ( Wide ) |
|
| Horizontal (left/right) |
±70° or 140° total |
| Vertical (up/down) |
70°(up), 70°(down) or 140° total |
| CPU |
Intel® Processor I3 (1.8GHz) |
| storage |
2G RAM;SSD 16G/32G Options |
| Serial Ports |
2 x COM ;RS232/RS485 |
| USB Ports |
2x USB V2.0; 2xUSB V3.0 |
| LAN |
1 x LAN RJ-45 connector |
| DC Power In |
1 x DC2.5 connector |
| Video Port |
1X Line-out |
| Other Ports |
1x LAN, 1X VGA ,1xHDMI,1X Audio |
| Internal Sockets & Connectors |
reserved for OEM project |
| Power Specification |
DC 12V |
| Working Environment |
| Temperature |
Operating: -10°C to 60°C ;Storage -20°C to 65°C |
| Operating Humidity |
5 ~ 90% RH @40°C (non-condensing |
| Vibration |
5 ~ 500Hz, 3Grms Random (with CF/SSD) |
| Dimensions |
| Mounting Type |
Embedded Installation,wall mounting |
| Mechanical dimensions |
339.0 x 225 x 47.0 mm |
| Weight (Net) |
3.5 kgs/ piece, 1 piece/ carton |
| Drawings |
Please contact us for details |
Packaging & Delivery
| Packing details |
1x 13 inch Open frame Industrial Touch Panel PC ;
Packed in 5 piece/carton with protection foam
Optional accessories:1x Power supply cable, 1x power adapter |
| Delivery terms |
7- working days for stock products after receiving payments; 15 working days for order production |
|
| Panel PC information |
|
| Model Number |
AXD-17PPC-A1 |
| 17' Touch panel pc |
| Case/Bezel Color |
Black |
| TFT Type |
Industrial LCD with LED backlight |
| Aspect ratio |
4:3 |
| Touch Panel |
Industrial 5 wire Resistive Flat Screen |
| Touch response time |
10ms (typical) |
| Optimal (native) Resolution |
1280x1024 |
| LCD panel Pixel pitch |
0.296 x 0.296 mm |
| LCD panel Colors |
16.7 million |
| LCD panel Brightness |
300 cd/m2 |
| LCD panel Response Time |
8ms |
| Contrast Ratio |
800:1 |
| Viewing Angle ( Wide ) |
|
| Horizontal (left/right) |
±80° or 160° total |
| Vertical (up/down) |
85°(up), 85°(down) or 170° total |
| CPU |
Intel® Celeron 1037U Dual Core 1.86GHz |
| storage |
16 G SSD ( optional) |
| Serial Ports |
2 x COM ports |
| USB Ports |
4 x USB |
| LAN |
1 x LAN RJ-45 connector |
| DC Power In |
1 x 4-pin connector |
| Video Port |
2X Audio |
| Other Ports |
2x LAN, 1XVGA,1xHDMI,1XLPT |
| Internal Sockets & Connectors |
1 x Compact Flash socket (reserved for OEM project) |
| Power Specification |
DC 12V |
| Working Environment |
| Temperature |
Operating: -10°C to 60°C ;Storage -20°C to 65°C |
| Operating Humidity |
5 ~ 90% RH @40°C (non-condensing |
| Vibration |
5 ~ 500Hz, 3Grms Random (with CF/SSD) |
| Dimensions |
| Mounting Type |
Embedded Installation |
| Mechanical dimensions |
386.5 x 318.47 x 57.7 mm |
| Weight (Net) |
7.5 kgs/ piece |
| Drawings |
Please contact us for details |
Features and Advantages1. Fanless Design; Ultra Slim and Compact Mechanical Design
2. High Luminance LCD Panel
3. Intel® Celeron 1037u Dual Core 1.8GHZ
4. 17 "1280X1024 Resolution Color TFT LCD Display
5. Fully IP54 Compliant Stainless Steel Chassis
6. Supp orts Wide Range DC Power Input (12V)
7. Intel® 16G SSD Compatible
8. Wake-on-LAN functionality for targeted centralized startup via a network
 |
| Panel PC Specifications |
|
| Model Number |
AXD-19OPPC-V1 |
| 19'' panel pc |
| Case/Bezel Color |
white |
| TFT Type |
Industrial LCD with LED backlight |
| Aspect ratio |
4:3 |
| Touch Panel |
Industrial 5 wire Resistive Flat Screen |
| Touch response time |
8ms (typical) |
| Optimal (native) Resolution |
1280X1024 |
| LCD panel Pixel pitch |
0.297 x 0.297 mm |
| LCD panel Colors |
16.7 million |
| LCD panel Brightness |
350 cd/m2 |
| LCD panel Response Time |
5ms |
| Contrast Ratio |
1000:1 |
| Viewing Angle ( Wide ) |
|
| Horizontal (left/right) |
±85° or 170° total |
| Vertical (up/down) |
80°(up), 80°(down) or 160° total |
| CPU |
Intel® Processor I3 (1.8GHz) |
| storage |
2G RAM;SSD 16G/32G Options |
| Serial Ports |
2 x COM ;RS232/RS485 |
| USB Ports |
2x USB V2.0; 2xUSB V3.0 |
| LAN |
1 x LAN RJ-45 connector |
| DC Power In |
1 x DC2.5 connector |
| Video Port |
1X Line-out |
| Other Ports |
1x LAN, 1X VGA ,1xHDMI,1X Audio |
| Internal Sockets & Connectors |
reserved for OEM project |
| Power Specification |
DC 12V |
| Working Environment |
| Temperature |
Operating: -10°C to 60°C ;Storage -20°C to 65°C |
| Operating Humidity |
5 ~ 90% RH @40°C (non-condensing |
| Vibration |
5 ~ 500Hz, 3Grms Random (with CF/SSD) |
| Dimensions |
| Mounting Type |
Embedded Installation,wall mounting |
| Mechanical dimensions |
423.0 x 327 x 53.0 mm |
| Weight (Net) |
7.5 kgs/ piece, 1 piece/ carton |
| Drawings |
Please contact us for details |
Features and Advantages
1.It's the latest evolution of Mini-ITX form factor industrial Motherboard with Dual GBE Lan.
2. It is based on Intel Celeron 3217U+HM76 chipset.Provide 2 Mini-PCIE and 1 Sim Slot to support Wifi/GPS/3G/ MSATA.
3. 1 SODIMM slot,Supports up to 8GB, SATA (1 Sata 3.0, 2x Sata 2.0)and MSATA storage modes.
4. It supports 1080P HD and independent Dual view, 1 HDMI and 1 VGA . Dual Channel 24bit LVDS.
 |
| Display Specifications |
|
| Display |
26" Color LED Industrial IR Touch Monitor |
| Model Name |
AXD-26OPN1T1-VT4 |
| Active Display Area (mm) |
575.77(H)x 323.71(V) |
| Pixel Pitch (mm) |
0.4215(H)x 0.4215(V) |
| Resolution (Pixel) |
1366X768;1920X1080 262,144(6 bit + FRC) |
| Brightness (CD/m^2) |
400cd/m^2 |
| Contrast Ratio |
1500:1 |
| Viewing Angle (CR >=10) |
176/176 wide view angle |
| Power consumption |
28.5 W typical, normal operation |
| Touch Screen |
IR anti-vandal ,water-proof, dust-proof touch |
| OSD Control |
On the back side |
| I/O Connectors |
1x12v,1XVGA,DVI-D(Optional) |
| Power Input |
DC 12V,4A48W Adapter |
| Mechanical Specifications |
|
| Construction |
Open frame steel metal material |
| Dimensions |
666.0x 376.2x 95.0(mm) |
| Mounting |
Embedded ,right and left ; VESA 75x75(100x100) Wall Mounting Optional |
| Power source |
AC 100~240V/ 12V DC |
| Environment Specifications |
|
| Operating Temperature |
0~60℃ |
| Storage Temperature |
-10~60℃ |
| Rating |
Facilitate installation of the demolition, solid portfolio |
| Ordering Information |
26.0” OP LED IR touch Monitor with VGA input and power adapter |
|
